|Fuel Type||Wood Burning|
|Style||Contemporary, Timeless, Traditional|
|Built From||Steel Body, Cast Iron Door|
|Flue Size||5" (125mm)|
|Flue Options||Top or Rear|
|Depth From Back To Centre Of Top Flue||145mm|
|Distance To Combustibles - Rear||350mm (50mm with Heat Shield)|
|Distance To Combustibles - Above||375mm|
|Distance To Combustibles - Sides||350mm|
|Height To Centre Of Rear Flue||675mm|
|12MM HEARTH INSTALLATION||Yes|
The ACR Neo 3F Eco design ready stove has four short cylindrical legs making it ideal for installing into ready built fireplace openings but also looks the part in a free standing installation. Being smoke exempt, you can burn wood on the Neo 3F in smoke controlled areas so whether you live in the town or the country, you can enjoy a real fire.
The large glass pane is kept clean by the powerful airwash giving an expansive view of the fire. For ease, the controls are operated from a single control on the front of the stove. Removing the ashes couldn’t be easier - the ashpan slides out towards you and a convenient carrying lid is then slotted into place allowing you to carry the ashes out without the worry of them getting blown about in the wind.
Easy ash removal system
Simple to use single air control
125mm flue collar diameter
Stove Glass – Accidental Damage Cover
The Stove Glass Accidental Damage Cover provides insurance for your stove glass for a 12 month or 24 month period. If your Stove Glass accidentally breaks within this period, we will send you a replacement. We do require a photograph to be sent.
The Cover period begins when the stove is dispatched.
Important: The Cover is only for 1 piece of glass, and does not cover the replacement glass.
A Carbon Monoxide Alarm is required to be installed in any room with a Solid Fuel Appliance including Wood Burning Stoves, Multi Fuel Stoves, Pellet Stoves and Gas Stoves. Further guidance on the installation of the carbon monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer’s instructions
Our 500mm and 1000mm lengths of Stove Pipe are designed to connect the Wood Burning or Multi Fuel Stove to the chimney systems including Flexible Flue Liner, Twin Wall Flue and Clay Pot Chimney Adaptors.
Closure Plate + Rosette
The Closure Plate [Register Plate] is required when installing a stove. It is designed to close the chimney off from the living area, preventing soot, dust and debris falling down the chimney. It helps to reflect heat back to the living area and minimize draughts from the chimney. Our Closure Plate measures 1000mm x 400mm, with a Pre-Cut 125mm [5 inch] or 150mm [6 inch] centre hole to allow the Stove Pipe to pass.
The Rosette is a finishing trim [125mm / 150mm] ] that is installed were the Stove Pipe passes through the Closure Plate.
External Air Kit
The External Air / Outside Air / Direct Air Kit, is a wall vent that can connect directly into the rear of the stove or air duct in the floor that provides air into the stove for combustion. It is an alternative to a standard wall vent. They are important in New Build Homes, New Extensions and well-sealed airtight rooms.
Half Price Fitting Kit
Our Half Price Fitting Kit is available for our range of Wood Burning and Multi Fuel Stoves and provides various options to install your new stove including Stove Pipe, Closure Plate and Carbon Monoxide Alarm.
Flexi Flue Liner Pack
Our Flexi Flue Liner Packs include a Flue Adaptor, Flexible Flue Liner 316 and a Chimney Cowl.
- Flue Adaptor – Connects the top of Stove Pipe to the bottom of the Flexible Flue Liner.
- Flexible Flue – Relevant length and diameter of Grade 316 Flue Liner.
- Chimney Cowl – The top part of the flue pack, designed to regulate draught, act as a bird guard and rain cap.
Our Packs have been designed to help you easily choose the exact length of Flexible Liner required for your property.
2-Blade Stove Fan
The 2-Blade Heat Powered Stove Fan is designed to circulate the warm air around the room. The fan gently and silently moves air from the hot zone around the stove toward the centre of the room, rather than rising to the ceiling, providing a more even distribution of the heat, a greater comfort and less fuel consumption.
The fan is self-powered using heat from the stove to operate. The fan does not require batteries or mains power.
Firewood Starter Bundle
Our Firewood Starter Bundle contains everything you need to light your first fire in your new stove. Each pack contains:
- 1 x Bag Kiln Dried Log with moisture content of less than 20%.
- 1 x Bag Kindling.
- 1 x Pack Fire Lighters.
